TROUBLE-SHOOTING
7-6 User's Manual
Tips for clearing a jammed sheet from the printer
If a sheet of paper is jammed between the print head and the platen and
cannot be removed, clear it as follows:
1. Turn off the printer and disconnect the power cord from the recepta-
cle.
2. Push up the locking levers to release the forms tractors and open the
paper holders.
3. Move the paper thickness lever to position D.
4. Move the print head so that you can remove the jammed sheet easily
and clear the sheet.
NOTE
The print head is hot immediately after printing. Move it after making
sure that it gets cool.
• If you cannot clear the
jammed sheet by the
above procedure, set
fourfold continuous
forms paper on the
forms tractors and turn
the platen knob to feed
the paper forward. The
jammed paper is pushed
out. Before operation, be sure to position the print head at the
center of the jammed paper.
