Setup Mode
USING SETUP MODE
User's Manual 5-31
Quick
Reference
Introduc-
tion
Setting Up
Paper
Handling
Printing
Setup Mode
Table 5.4 HARDWRE Items and Options (Cont.)
NOTE: Underlined options are the factory defaults.
HARDWRE
Items
Options Description
NOTE:
(continued) • 0BYTE option is recommended
only for graphics application.
• With 128KB selected, the printer
cannot accept any download font
data.
Selects the type of the interface to the
computer.
PARALEL Centronics parallel interface
SERIAL RS-232C serial interface
USB USB interface
AUTO-2S Auto interface selection mode
AUTO-4S • Both interfaces are ready for
AUTO-6S communication.
AUTO10S • Specify the timing regarding the
AUTO15S selected interface as being inactive.
AUTO20S To switch the interface to the optional
LAN interface, mount the LAN card with
the setup mode set to "AUTO-XS" or
"AUTOXXS" under "INTERFCE," which
in turn is under "HARDWRE" The
interface will automatically switch to the
optional LAN interface.
To switch the interface to something other
than the optional LAN interface, do either
of the following:
• To return the setup mode to
"INTERFCE" under "HARDWRE,"
remove the LAN card.
• To switch the interface to a fixed
interface, set PARALEL,USB with the
LAN card mounted, and the setup mode
set to "INTERFCE" under
"HARDWRE."
Serial Interface or USB interface Items. The following to
items are not printed when you select the PARALEL option for the
item. Be sure that the options selected on the printer are the same as
the options selected using your computer operating system or your software.
Refer to the documentation provided for your computer and software.
