SETTING UP
2-20 User's Manual
Shutter
Connecting the Interface Cable
To connect the interface cable:
1. Turn off both the printer and the computer.
2. Pull the shutter on the left side of the printer upward as far as it will go.
Opening the shutter
NOTE
Removing and Attaching the Shutter
When use of the shutter is not required, remove it by using the following
procedure.
Selecting a USB Cable
√
When the USB interface is used to connect to the host computer, the
parallel interface and the serial interface (factory add-on option) cannot
be connected simultaneously.
√
The USB interface does not guarantee all connections of USB-
supported devices.
Selecting a LAN cable
√
When the LAN cable is connected, the parallel and USB cables cannot
be used.
√
The LAN cable, when used in 100BASE-TX environments, must
conform to category 5 or higher.
