FTP-634MCL001/002/FTP-624DCL/DSL002
■ OVERVIEW
FTP-634MCL/FTP-624DCL/DSL Series is a high speed line
thermal printer driven by battery, printing on 3-inch wide paper
(80 mm/ 85 mm).
The printer is compact and lightweight, and the design allows
easy head maintenance, head cleaning and head
replacement.
This printer is suitable for a variety of applications, such as
hand held terminals, POS terminals, ticket machines, coupon
machines, label printers, etc.
■ HIGHLIGHTS
• High speed printing
It can print at 50 mm/s (400 dotlines/s) maximum by using
Fujitsu
Components' unique head drive control.
• Compact and lightweight
This printer has a low profile of only 20 mm, and a light
weight of approximately 95g.
• Low power consumption
The peak current for head drive is only 3.5 A (8.5 VDC, 128
dots on).
• Easy head access
It is designed for easy head cleaning and head replacement.
• Paper auto loading function
Thermal paper can be loaded without head-up lever
operation.
• UL recognized
File No. E171434
BATTERY DRIVE, FTP-604 Series
3” TYPE MECHANISM AND INTERFACE BOARD
FTP-634MCL001
FTP-624DCL/DSL002
FTP-624CU102
1
