3» .1, 3« 1 5-Insfa 11 a new gear cover
gasket*
if
a
3.3* 3*17-Install the correct
bolt and fiat washer into count
erbalance alignment hole* USE
THE COEUIECT BOLT - if bolt is Coo
long, dainagp to counterbalance
will result.
3,3,3*19-Tnstall upper and lower
valve spring retainers over ends
of valve springs. Keep intake and
exhaust valve parts together as a
set. See illustration for correct
retainer locations.
3.3.3*16-Align
dowel
pin
on cyl'
inder block with dowel pin hole
on engine gear cover. Install
gear cover. When cover is flush
against cylinder block, remove
bolt from counterbalance align-
ment hole.
3
.
3
.
3
.
18
-Retaln engine gear cover
to cyiinder block with bolts and
lockwashers. Tighten all bolts to
00-110 inch-pounds.
3.3-11
