2#_l_Ll2_6-Use a lO nim \^пгRт^ch to rem
ove blower, scroll bolts nearest the
pngine taper shaft. The bolt at low
er right comer of blower scroll ex
tends through the shrouding and is
retained by a lock washer, flatwash-
er and hex nut on shroud exterior.
Use a 7/16 inch wrench to remove the
bolt and nut.
3.1.1,7-RemoVP four MlO bolts and
four lockwashers that retain Che cy
linder head cover. Remove cylinder
head cover.
Wmm
il
3.1.1.8-Remove two M8 socket head 3.1.1.9-Remove bolt and washer Chat
capscrews that retain the exhaust
pipe to engine.
retains housing and exhaust pipe
support to vibration dampener.
3.1,1,lU-Use a nut driver to remove
screws that retain blower housing
upper ends to engine. Remove blower
housing.
3.1-2
