SECTION 3.3

ENGINE SECTION

3.3.1- DISASSEMBLY

3.3.1. l-Dlsconnect. governor spring

from governor adjusting screw. Loo

sen governor arm'clamp bole and re

move governor arm from governor

shaft.

3.3.1.3-Ramovp engine from alterna

tor slide pan.

3.3.1.2-Remove spark plug.

3.3.1.4-Remove breather assembly.

i i I

3.1.5-Remove intake manifold elbow. 3.1.1_._6-Remove engine cowling.

3.3-1
