3»2., 1« 13-Remove starter cable at
the starter terminal.
3.2.1.15-At the terminal strip,
disconnect the wire from the fuel
lockoff solenoid.
3.2.1.14-Cur Wires No. 8 and 25
that go to the ignition stator.
3.2.1.16-Remove fuel Line at carb­
uretor. Carburetor to intake luaui-
fold iiuLs may also be loosened at
this time. These nuts will be cioni-
pletely rpTTioved prior to removal
of the adapter casting (Step 3.2.
1.17).
3.2.1.l7-Rcmovc bolts, nuts and
washers that retain the adapter
casting. Remove carburetor to
intake manifold nuts, then rem­
ove adapter casting.
3.2.1.19-Use rotor removal kit
to remove rotor. (See Section
1.3, SPECIAL TOOLS.) Use the
5/16-24 tap from kit to cut
threads in totor as shown at
right.
3.2.1.18-Remove -rotor bolt.
3.2-3
