Genesis II Installation Instructions
Page 86 © Mass Electronics Pty Ltd 2010 Edition 2.0 dated 06/12/2013
Current value is determined by measuring voltage across a resistor in series.
NOTE
AISC Model Input Type
Parameter
Measured
Expected Value
Reference
Paragraph
DO5 Digital Voltage 0 or 5VDC 4-1.2.7
D33 Digital Voltage 0 or 10VDC 4-1.2.7
IO5 0 - 5mA Passive Current (see Note) 0 - 5mA 4-1.2.8
I20 4 - 20mA Passive Current (see Note) 4 - 20mA 4-1.2.8
P20 Loop Powered Inspect Wiring N/A 4-1.2.8
TD1 Current Loop Current (see Note) 0- 250µA 4-1.2.8
TD2 0 - 500µA Current (see Note) 0 - 500µA 4-1.2.8
TH1 Thermistor Resistance 0 - 1kΩ 4-1.2.9
TH2 Thermistor Resistance 0 - 2kΩ 4-1.2.9
TH3 Thermistor Resistance 0 - 3.8kΩ 4-1.2.9
TH4 Thermistor Resistance 0 - 8.2kΩ 4-1.2.9
TH5 Thermistor Resistance 0 - 16.2kΩ 4-1.2.9
TH6 Thermistor Resistance 0 - 33.3kΩ 4-1.2.9
TH7 Thermistor Resistance 0 - 68.1kΩ 4-1.2.9
TH8 Thermistor Resistance 0 - 121kΩ 4-1.2.9
TH9 Thermistor Resistance 0 - 221kΩ 4-1.2.9
V05 Voltage Voltage 0 - 5VDC 4-1.2.7
V10 Voltage Voltage 0 - 10VDC 4-1.2.7
Table 4-3: Analogue Input Checks
