Genesis II Installation Instructions
© Mass Electronics Pty Ltd 2010
Chapter 3 – Electrical Installation
3-3.2 MPCII Mid Points Controller
Figure 3-4 shows the input/output connection groups for the MPCII Mid Points Controller. The MPCII
Mid Points Controller uses terminal strips located around the controller’s perimeter. Terminals are
grouped by function as follows:
• Power
Input
)
• Digital
Inputs
)
• Digital
Outputs
)
• Analogue
Inputs
)
• Analogue
Outputs
)
• Remote Expansion Modules (REM) Connector
)
• RS232 Serial Communications (Comms) Port
• Net & Global Communications (Comms, RS485) Terminal (
RS
-232 COMMS
COMMS
NET
COMMS
REM
GLOBAL
COMMS
MPC
Cobar
POWER
DIGITAL INPUTS
SCREENS
ANALOGUE INPUTS
RS232
CONNECTOR
REM
PORT
RS485
COMMS
ANALOGUE
OUTPUTS
DIGITAL OUTPUTS
Figure 3-4: MPCII Mid Points Controller Input / Output Terminals
