Genesis II Installation Instructions
© Mass Electronics Pty Ltd 2010
Chapter 3 – Electrical Installation
The RS485 Comms connection block is in the upper right section of the module and the End of Cable
Jumper is next to it.
Digital Input terminals are located at the bottom of the module; input signal connections are listed in
Terminal
Signal
A
DI 1+
B
DI 2+
C
DI 3+
D
DI 4+
E
DI 5+
F
DI 6+
G
DI 7+
H
DI 8+
I
Common
J
Common
Table 3-15:
GENII DI REM Digital Input Signal Conditions
