Genesis II Installation Instructions
Page 66
© Mass Electronics Pty Ltd 2010
Edition 2.0 dated 06/12/2013
3-4.15 GENII MP414 REM Multipoint Module
The Innotech GENII MP414 REM Multipoint Module is a remote expansion device that has both input
and output expansion capabilities. The GENII MP414 REM provides relay outputs for distributed
control, digital inputs for status detection and Thermistor inputs for temperature measurement.
The GENII MP414 REM (Figure 3-19) is powered by 24VAC ±10% @ 50/60Hz, or powered by 24VDC ±15%.
Power Consumption is 4 VA maximum.
Inputs:
• 10 kΩ thermistor temperature sensor.
• 4 x 24VAC or DC Isolated switched contact digital inputs.
Outputs:
• 4 x 24VAC or DC Relay Outputs, Normally Open contacts. Rated at 16 Amp Resistive, 6 Amp
Inductive.
• 1 x Analogue Output, 0-10VDC ±0.05V into > 2 kΩ load.
C
O
N
TR
O
L
S
Y
S
TE
M
S
A
U
S
TR
A
L
IA
®
MP414
NOTE:
24V AC /DC
ALL OUTPUT RELAYS:-
Rated at :
16Amp R esistive
6Amp Inductive
Com = Common Contact
NO = Normally Open Contact
ANALOGUE OUTPUT:-
Rated at :
0-10VDC into >2 k Loa d
(Voltage Free Contacts by other)
DIGI TA L I NPUT S
+24V
0V
DI#+
DI#-
NOTE:
ALL DIGITAL INPUTS:-
Ra ted at :
24V (AC or DC)
(Voltage Free Contacts by other)
TYPICAL DIGI TA L I NPUTS
+24V
SENSOR
C+
C-
S2
S1
Comms
24V AC or DC Supply
0V AC or DC Supply
0V
EARTH
D
I 4
D
I 1
D
I 2
D
I 3
+
-
Comm
s
Jum
pers
A2
A1
A0
TERM
SHLD2
SHLD1
TH2
TH1
+
-
+
-
+
-
+
-
Com
NO
D
O
1
+
AO
-
1
D
O
2
D
O
3
D
O
4
0
V
24V
Com
NO
Com
NO
Com
NO
E
D
I 4
D
I 1
D
I 2
D
I 3
+
-
Comms
Jumper
s
A2
A1
A0
EOL
SHLD2
SHLD1
TH2
TH1
+
-
+
-
+
-
+
-
The RS485 Comms connection block is in the lower-left section of the module (as illustrated above)
and the End of Cable Jumper is next to it.
The unit must be powered down before jumpers are altered. Anti-static precautions should be taken when changing
addresses or adding or removing cabling from the terminals.
IMPORTANT
Figure 3-19: GENII MP414 REM Multipoint Module
