Chapter 2 TC2201 Web Interface
Statistics Page
Quantum TC2201 User’s Guide 38
• To delete a specific map entry, select an Index from the pull-down list
under Delete Map Item. To delete multiple Indexes, also select the
end of the range from the optional pull-down list. Either way, select
the
Delete Entry
button to remove the item(s) from the map.
• To create a specific map item, the Index, Bus, and Device can be
selected from the pull-down lists for either Discovered Device Entry
or Manual Device Entry. Discovered Device Entry is limited to
devices already discovered. Manual Device Entry allows you to
manually set up a device type at a specific Device Target and Device
LUN. To make the changes permanent, select the
Create Entry
button.
Statistics Page
2
The
Statistics
page shows SCSI bus statistics.
To access the
Statistics
page:
1
Click
Statistics
from the
Main
menu on the
Home
page.
The
Statistics
page displays (see figure 28 ):
Note:
Maps named ‘Auto Assigned’ may not be modified, cleared,
filled, or have entries removed.
Note: Map settings are saved to memory when any of the buttons
within the page are selected but are not activated until either
the
Activate Mapping Changes
button is selected or the TC2201
is rebooted.
