Page 121
Status
Indicates the current IPX/SPX protocol status.
Ready
the print server is awaiting data over IPX/SPX.
●
Disabled
IPX/SPX was manually disabled.
●
Initializing
the print server is registering the node address or
name. An additional status message may also be displayed.
●
An
are displayed if the print server is not ready.
Node Name
[This line appears here only for the 175x
For the 310x, this line appears
in the Novell/NetWare section instead
The IPX/SPX name of the print server. The default name is
NPIxxxxxx
,
where
xxxxxx
is the last six digits of the LAN hardware (MAC) address.
Primary
Frame
Type
Specifies the frame type selection on the print server.
Auto Select
the print server automatically senses and limits the
frame type to the first one detected.
●
EN_II
limits the frame type to IPX over Ethernet frames. All others
will be counted and discarded.
●
EN_802.2
limits the frame type to IPX over IEEE 802.2 with IEEE
802.3 frames. All others will be counted and discarded.
●
EN_SNAP
limits the frame type to IPX over SNAP with IEEE 802.3
frames. All others will be counted and discarded.
●
EN_802.3
limits the frame type to IPX over IEEE 802.3 frames. All
others will be counted and discarded.
●
Network
The first column “
Network
” indicates the network number associated with
each protocol frame type used for communication between a server and the
print server.
Unknown
the print server is still trying to determine which network
number to use.
●
Frame
Type
EN_II
EN_802.2
EN_SNAP
EN_802.3
The second column “
Frame Type
” identifies the frame type associated with
each network number.
Unless a specific frame type has been manually configured, the print server
automatically determines the protocol frame type by listening to the network
data being transferred over the network.
Disabled
a specific frame type for that network has been manually
configured.
●
Rcvd
The third column “
Rcvd
” indicates how many packets have been received for
each frame type.
Novell/NetWare Protocol Information
Provides the current status and parameter values for the Novell NetWare network protocol.
This section appears only for the 310x.
Message
Description
