Page 49: Server dimensions and values

Table 3-1 HP 9000 rp3410 and rp3440 Server Features (continued)

rp3440

rp3410

Features

Integrated Ultra-3 SCSI dual-channel controller;
80 MBs transfer rate with one internal 68 pin
connector and one external 68 pin connector.

N/A

SCSI

PCI Gigabit, fast Ethernet controller

LAN

Four 64 bit hot-pluggable PCI-X slots, 133 MHz,
3.3V slots

Two 64 bit hot-pluggable PCI-X slots, 133 MHz,
3.3V slots

PCI Slots

Three serial ports, 4 USB 2.0 ports, integrated
RJ-45 LAN on iLO MP card.

Core I/O

IDE interface; 48x speed

N/A

DVD

Two-port U320 PCI-X RAID Smart Array 6402
(A9890A Controller)

External Storage

Redundant, (2N+1) 714 Watt

Power Supply

HP-UX 11i v1, HP-UX 11i v2, and HP-UX 11i v3
(choice of Enterprise, Mission-Critical, Technical
Computing, and Foundation operating
environments)

HP-UX 11i v1, HP-UX 11i v2, and HP-UX 11i
v3 (choice of Enterprise, Mission-Critical,
Technical Computing, and Foundation
operating environments)

Operating
Systems

Firmware

Firmware consists of many individually linked binary images that are bound together by a single
framework at run time. Internally, the firmware employs a software database called a device
tree to represent the structure of the hardware platform and to provide a means of associating
software elements with hardware functionality.

The firmware incorporates Boot Console Handler (BCH) which provides an interface between
the operating system and the platform firmware.

The firmware supports the HP-UX 11i version 1 (and higher HP-UX versions that support
PA-RISC systems) operating system through the HP 9000 processor family standards and
extensions, and has no operating system-specific functionality included. The operating system
is presented with the same interface to system firmware, and all features are available to the
operating system.

Event IDs for Errors and Events

The server firmware generates event IDs similar to chassis codes for errors, events, and forward
progress to the iLO MP through common shared memory. The iLO MP interprets and stores
event IDs. Reviewing these events helps you diagnose and troubleshoot problems with the server.

Dimensions and Values

Table 3-2

lists the dimensions and their values of the HP 9000 rp3410 and rp3440 servers.

Table 3-2 Server Dimensions and Values

Values

Dimensions

26.8 in (67.9 cm) max x 19.0 in (48.3 cm) x 3.4 in (8.6 cm)
26.6 in (67.5 cm) x 11.6 in (29.5 cm) x 19.5 in (49.4 cm)

Rack dimensions (depth x width x height)
Pedestal dimensions (depth x width x height)

Minimum: 38.6 lbs (17.5 kg)
Maximum: 49.0 lbs (22.2 kg)

Minimum: 49.4 lbs (22.4 kg)

Maximum: 56.3 lbs (25.5 kg)

Rack weight
Pedestal weight
