Table 1-4 Extended Core I/O Paths (continued)

ACPI Path

Location

Function Associated with Path

Slot

0/0/3/0

Rear panel (with LAN
10/100 label)

LAN 100 port

Core I/O

0/1/1/0

System board

Ultra 3 SCSI Channel A

Core I/O

0/1/1/1

System board

Ultra 3 SCSI Channel B

Core I/O

0/1/1/1.x.y

Rear panel (with SCSI
LVD/SE label)

Ultra 3 SCSI I/O— external SCSI

Core I/O

0/1/2/0

Rear panel (with LAN
GV label)

LAN 1000 port

Core I/O

0/7/1/1

Rear panel (accessible
thru W cable)

Interface with external console (ECI)

Console port

0/7/1/0

Rear panel (accessible
thru W cable)

Interface with UPS (ECI)

Remote port

N/A

Rear panel (accessible
thru W cable)

Interface with UPS

UPS port

0/7/2/0

Rear panel (with VGA
label)

Not used (disabled)

ECI (VGA
port)

Factory use only

Rear panel (with Serial
A label)

Baseboard console port (CLI)

N/A

Factory use only

Rear panel (with Serial
B label)

Baseboard serial port

N/A

Table 1-5

describes the PCI I/O paths for the server.

Table 1-5 PCI I/O Paths

ACPI Path

Location

Function Associated with Path

Slot

0/4/1/0

Top connector/slot in
PCI card cage

64-bit, 133 MHz PCI-X card

Slot 1

0/3/1/0

Second connector/slot
in PCI card cage

64-bit, 133 MHz PCI-X card

Slot 2

0/2/1/0

Third connector/slot in
PCI card cage

64-bit, 133 MHz PCI-X card (active rp3440 only)

Slot 3

0/6/1/0

Bottom connector of
PCI card cage

64-bit, 133 MHz PCI-X card (active rp3440 only)

Slot 4

Table 1-6 PCI I/O Hardware Paths

HP-UX Path

MAPPER Path

PCI Card Functionality

0/0/1/0

0/0/1/0

USB Port

0/0/1/0

0/0/1/0

USB Port

0/0/1/1

0/0/1/1

USB Port

0/0/1/1

0/0/1/1

USB Port

0/0/2/0

0/0/2/0

IDE Controller

0/0/2/0.0.0

0/0/2/0.0.0

DVD Drive

0/1/1/0.0.0

0/1/1/0.0.0

Internal SCSI - Slot 0

0/1/1/0.1.0

0/1/1/0.1.0

Internal SCSI - Slot 1

30
