The air is pulled through openings in the front cover and the mass storage devices and pushed
through the PCI card cage.Perforation is provided between and above the PCI card cage to enable
proper exhaust ventilation to maintain the required temperature rating of the PCI cards.
CAUTION: For maximum cooling effects, ensure that the chassis ventilation holes are not
blocked or covered after installation.
Acoustic Noise Specification
The acoustic noise specification for the HP 9000 rp3410 or rp3440 servers is 53 db LpA (sound
pressure level at bystander position in a dedicated computer room environment temperature of
<25°C).
Physical and Environmental Specifications
Table 2-7 provides temperature and airflow information for minimum, typical, and maximum
configurations for the HP 9000 rp3410 and rp3440 servers. It also lists the server and rack weights
and dimensions.
Table 2-7 Physical and Environmental Specifications
Overall Server
(W x D x H)
Weight Condition
Airflow, at
Maximum
Ambient Degrees
C
1
Airflow, Nominal Typical
Heat
Release
Pedestal Rack Pedestal Rack Server
Alone 100-250
VAC
W: 11.6 in
(29.5 cm)
D: 26.6 in
(67.5 cm)
H: 19.5 in
(49.4 cm)
W: 19.0 in
(48.3 cm)
D: 26.8 in
(67.9 cm)
H: 3.4 in
(8.6 cm)
56.3 lbs
(25.5
kg) 49.0 lbs
(22.2 kg) 38.6 lbs
(17.5 kg) 115.94
m3/hr
68.2
CFM
98.3
m3/hr
57.8
CFM
341 Watts Min.
Config.
536 Watts Max.
Config.
426 Watts Typical
Config.
One dual-core CPU, one power supply, 2 GB DIMM,
zero DVD, three HDDs. Min./
Config. Airflow cooling scheme (front to rear) ASHRAE
Class 1
Two dual-core CPUs, one power supply, 32 GB
DIMM, one DVD, three HDDs, one graphics card,
one SCSI card. Max.
Config.
One dual-core CPU, one power supply, 6 GB DIMM,
one DVD, three HDDs, one graphics card, one SCSI
card. Typical
Config.
1 Derate maximum dry bulb temperature 1 degree per 300 meters above 900 meters.
46 System Specifications
