IDE Interface
The IDE controller (PCI649) supports the ATAPI zero (0) to five (5) modes (from 16 to 100 MB/s).
The usable speed on this system is limited to 16 MHz (ATA-33 mode, 33 MB/s) because the
slimline CD/DVD devices do not support the ATA-66 and 100 modes.
The primary IDE channel is the only channel that is implemented. The IDE cable provides only
one drive connector, of the master type, for the optical storage peripheral.
1 GB System LAN
The 1 GB System LAN port provides:
• Main system LAN
• 10/100/1000 MB capable
USB Connectors
The USB connectors provide:
• High speed 480 MB/seconds capable
• Full speed 12 MB/seconds and low speed 1.5 MB/seconds
• Support for USB keyboard and mouse
• HP-UX supports HP USB keyboard and mouse
Disk and I/O Path Logging
Some failures result in I/O path logging. These paths help to indicate the source of the error and
can be included in the error message or logged into console or event logs.
Table 1-3 describes the disk drive and DVD paths for the server.
Table 1-3 Internal Disk and DVD Paths
ACPI Path Location Function Associated with Path Slot
0/1/1/0.0.0 Bottom disk slot Ultra 3 SCSI I/O for bottom removable disk Disk slot 0
0/1/1/0.1.0 Middle disk slot Ultra 3 SCSI I/O for middle removable disk Disk slot 1
0/1/1/1.2.0 Top disk slot Ultra 3 SCSI I/O for top removable disk Disk slot 2
0/0/2/0.0.0 DVD slot IDE I/O for DVD DVD slot
Table 1-4 describes the extended core I/O paths for the server.
Table 1-4 Extended Core I/O Paths
ACPI Path Location Function Associated with Path Slot
0/0/1/0 Rear panel (with
mouse symbol) USB port Core I/O
Rear panel (top/ white
connector) 0/0/1/0 USB port Core I/O
0/0/1/1 Rear panel (with
keyboard symbol) USB port Core I/O
0/0/1/1 Rear panel
(bottom/white
connector) USB port Core I/O
0/0/1/2 Internal USB port Core I/O
0/0/2/0 System board IDE controller Core I/O
Detailed Server Description 29
