Table 1-14 SCSI Port Pinouts (continued)
Signal Description
Pin Number
Signal Description
Pin Number
S39 (–DB P1)
39
S5 (+DB P1)
5
S40 (–DB 0)
40
S6 (+DB 0)
6
S41 (–DB 1)
41
S7 (+DB 1)
7
S42 (–DB 2)
42
S8 (+DB 2)
8
S43 (–DB 3)
43
S9 (+DB 3)
9
S44 (–DB 4)
44
S10 (+DB 4)
10
S45 (–DB 5)
45
S11 (+DB 5)
11
S46 (–DB 6)
46
S12 (+DB 6)
12
S47 (–DB 7)
47
S13 (+DB 7)
13
S48 (–DB P)
48
S14 (+DB P)
14
S49
49
S15
15
S50
50
S16 (DIFFSENS)
16
S51 (TERMPWR)
51
S17 (TERMPWR)
17
S52 (TERMPWR)
52
S18 (TERMPWR)
18
S53 (RESERVED)
53
S19 (RESERVED)
19
S54
54
S20
20
S55 (–ATN)
55
S21 (+ATN)
21
S56
56
S22
22
S57 (–BSY)
57
S23 (+BSY)
23
S58 (–ACK)
58
S24 (+ACK)
24
S59 (–RST)
59
S25 (+RST)
25
S60 (–MSG)
60
S26 (+MSG)
26
S61 (–SEL)
61
S27 (+SEL)
27
S62 (–C/D)
62
S28 (+C/D)
28
S63 (–REQ)
63
S29 (+REQ)
29
S64 (–I/O)
64
S30 (+I/O)
30
S65 (–DB 8)
65
S31 (+DB 8)
31
S66 (–DB 9)
66
S32 (+DB 9)
32
S67 (–DB 10)
67
S33 (+DB 10)
33
S68 (–DB 11)
68
S34 (+DB 11)
34
iLO MP Card LAN LEDs
The iLO MP card LAN uses an RJ-45 type connector. This connector has four LEDs that signal
status and activity.
shows the iLO MP card LAN LEDs.
Controls, Ports, and LEDs
37
