Figure 6-3 Release the Rack Latches
3. Slide the server out of the rack until the guide-rail release clips are visible.
Inserting the Server Into the Rack
To insert the server into the rack, follow these steps:
1. Press the rail clips on either side of the server inward and push the server into the rack until
it stops.
2. Verify that the rack latches are closed.
Removing and Replacing the Top Cover on a Rack-Mounted Server
Removing the Top Cover on a Rack-Mounted Server
NOTE: If you are replacing a hot-swappable item, you can leave the server on and external
cables (including the power cord) connected.
To remove the top cover, follow these steps:
1. Power off the server and disconnect the power and external cables from the back of the
server.
2. Ensure the top cover lock keyswitch is in the unlocked position. Rotate the blue release lever
toward the back of the server and slide the cover toward the back of the server.
Removing and Replacing Server Covers and Bezel 127
