HP RP3440 - Manual (Page 130)

2. Close the bezel and push toward the front of the server until it locks into place.
Figure 6-8 Replacing the Front Bezel on a Rack-Mounted Server
Accessing a Pedestal-Mount Server
Both the HP 9000 rp3410 and the rp3440 servers are available in a pedestal configuration or can
be converted from a rack to a pedestal configuration. To access the internal components on a
pedestal server, you must remove the side and top covers.
Removing the Side Covers on a Pedestal-Mounted Server
NOTE: If you are replacing a hot-swappable item, you can leave the server on and external
cables (including the power cord) connected.
To remove the side covers, follow these steps:
1. Power off the server and disconnect the power and external cables.
130 Removing and Replacing Components
