2 System Specifications
This chapter provides information on the basic system configuration, physical specifications,
and requirements for the HP 9000 rp3410 or rp3440 server.
System Configuration
lists the minimum and maximum configuration options for the HP 9000 rp3410 and
rp3440 servers.
Table 2-1 Minimum and Maximum System Configurations
rp3440
rp3410
Component
One or two dual processor modules each
containing two PA RISC processors. Each
processor is 800 MHz/1.5 MB cache or 1
GHz/1.5 MB with 32 MB or 64 MB L2 cache.
One dual processor module with one or two
PA RISC processors enabled. Each processor
is 800 MHz/1.5 MB cache with 32 MB or 64
MB L2 cache.
Microprocessors
Supports up to 12 double data rate (DDR)
registered ECC memory, in PC2100 DIMMs.
Maximum memory capacity is 32 GB if 4 GB
DIMMs are used. Supported DDR DIMM
sizes: 256 MB, 512 MB, 1 GB, 2 GB, and 4 GB.
Supports up to 12 double data rate (DDR)
registered ECC memory, in PC2100 DIMMs.
Maximum memory capacity is 6 GB.
Supported DDR DIMM sizes: 256 MB, 512
MB, and 1 GB.
Memory
Three 36 GB, 15K RPM Ultra320 SCSI hot-plug
disks or three 73 GB, 15K RPM Ultra320 SCSI
hot-plug disks or three 146 GB, 10K RPM
Ultra320 SCSI hot-plug disks.
Three 36 GB, 15K RPM Ultra320 SCSI
hot-plug disks or three 73 GB, 15K RPM
Ultra320 SCSI hot-plug disks or three 146
GB, 10K RPM Ultra320 SCSI hot-plug disks.
HDDs
Integrated Ultra-3 SCSI dual-channel
controller; 80 MB/s transfer rate with one
internal 68-pin connector and one external
68-pin connector.
Integrated Ultra-3 SCSI dual-channel
controller; 80 MB/s transfer rate with one
internal 68-pin connector and one external
68-pin connector.
SCSI
PCI GB, fast Ethernet controller.
PCI GB, fast Ethernet controller.
LAN
Four 64-bit PCI-X slots, 133 MHz, 3.3V slots.
Two 64-bit PCI-X slots, 133 MHz, 3.3V slots.
PCI slots
One serial port, four USB 2.0 ports, integrated
RJ-45 LAN on iLO MP card.
One serial port, four USB 2.0 ports,
integrated RJ-45 LAN on iLO MP card.
Core I/O
IDE interface; 48x speed.
None.
DVD
Optional.
Optional.
External storage
One 650W power supply. You can install a
second power supply to provide redundant
(N+1) capability.
One 650W power supply. You can install a
second power supply to provide redundant
(N+1) capability.
Power supply
Dimensions and Values
lists dimensions and values of the HP 9000 rp3410 and rp3440 servers.
Table 2-2 Server Dimensions and Values
Values
Dimension
26.8 in (67.9 cm) max. x 19.0 in (48.3 cm) x3.4 in (8.6 cm)
26.6 in (67.5 cm) x 11.6 in (29.5 cm) x 19.5 in (49.4 cm)
Rack dimensions (depth x width x height)
Pedestal dimensions (depth x width x height)
Minimum: 38.6 lbs (17.5 kg)
Maximum: 49.0 lbs 22.2 kg
Minimum: 49.4 lbs 22.4 kg
Maximum: 56.3 lbs 25.5 kg
Rack weight
Pedestal weight
System Configuration
41
