5.10.2 System Configuration Errors
Error Code Name Description
100 Too many binary input points Too many binary input points are configured for
the module. Maximum value is 15360.
101 Too many binary output
points Too many binary output points are configured for
the module. Maximum value is 15360.
102 Too many counter points Too many counter points are configured for the
module. Maximum value is 480.
103 Too many analog input points Too many analog input points are configured for
the module. Maximum value is 960.
104 Too many analog output
points Too many analog output points are configured for
the module. Maximum value is 960.
105 Too many binary input events Too many binary input events are configured for
the module. Maximum value is 400.
106 Too many analog input
events Too many analog input events are configured for
the module. Maximum value is 400.
107 Invalid analog input
deadband Deadband value for analog input events is out of
range. Value must be in the range of 0 to 32767.
108 Not enough memory There is not enough memory in the module to
configure the module as specified.
109 Invalid block transfer delay for
blocks 251 and 252
(error/status blocks) Block transfer delay value specified is too low.
110 File count invalid The file count must be in the range of 0 to 6.
111 Invalid file record size The file record size must be in the range of 1 to
120.
112 Invalid block identification
code for file The file block transfer code must be in the range of
100 to 120.
5.10.3 DNP Port Configuration Errors
Error Code Name Description
212 Invalid DNP address The DNP address specified in the configuration is
not valid (0 to 65534).
213 Invalid DNP port baud rate The baud rate code specified in the configuration
is not valid.
219 Invalid DNP data link layer
confirm mode The data link confirmation mode code is not valid
in the configuration.
220 Invalid DNP data link confirm
time-out The data link time-out period specified in the
configuration is 0. It must be an integer in the
range of 1 to 65535.
222 Invalid DNP select/operate
arm time duration The select/operate arm timer is set to 0. It must be
an integer in the range of 1 to 65535.
223 Invalid DNP application layer
confirm time- out The application layer confirm time-out value is set
to 0. It must be an integer in the range of 1 to
65535.
