KEPCO MBT Series - Manual (Page 19)

MBTSVC111609
1-3
STATIC
Source Effect
Voltage 0.001% EOMAX
Current 0.005% IOMAX
Load Effect
Voltage 0.002% EOMAX
Current 0.024% IOMAX or 4mA (whichever is greater)
Time Effect (8 Hour Drift)
Voltage 0.01% EOMAX
Current 0.02% IOMAX
Temperature Coefficient
(per oC)
Voltage 0.01% EOMAX
Current 0.02% IOMAX
Ripple & Noise (rms/p-p)
Voltage 0.001%/0.01% EOMAX or 0.3mV/3mV (whichever is greater)
Current 0.03%/0.3% IOMAX
MISCELLANEOUS
Series/Parallel Operation Consult Kepco applications engineering.
Leakage Current Common mode current: 5
µ
A rms or 50
µ
A p-p @ 115V a-c
Temperature
Storage −
20o C to +70o C
Operating
0o C to 50o C
Cooling Built-in fan, exhausts air to rear.
D-C Output Terminals Binding posts; barrier strip for remote sensing and monitor connections.
Local voltage/current control
Output can be controlled by entering the desired value via front panel keypad or continuously
(inherent resolution) adjusted via front panel control knobs.
Remote Error Sensing Provision for 4-terminal (Kelvin) connection to load; static drop of up to 0.5V/lead may be compen-
sated.
Voltage Recovery for a Step
Load Current 100
µ
sec typical, 150
µ
sec max to recover within 10mV for a 10% to 100% step in rated load cur-
rent.
PHYSICAL
Dimensions See Figure 1-2.
Weight (lbs.) Model M: 35; Models MR, MG: 36; Model MGR:37
Source Connections Detachable IEC type 3-wire power entry.
Load Connections Binding Post
Remote Control Signal
Connections
IEEE 1118 Two 9-Pin D-type connectors (female) in parallel for input/output daisy
chain.
RS232-C 9-Pin D-type connector (male)
IEEE 488 24-Pin connector (female)
Sense, Monitor Connections Barrier strip
TABLE 1-2. GENERAL SPECIFICATIONS (CONTINUED)
CHARACTERISTIC REQUIREMENT
