CHAPTER 4: PERIPHERAL CIRCUITS AND OPERATION (Serial Interface)

Table 4.11.1.1 Configuration of input/output terminals

Terminal

When serial interface is selected

P10

P11

P12

P13

SIN

SOUT

SCLK

SRDY

* The terminals used may vary depending on the transfer mode.

SIN and SOUT are serial data input and output terminals which function identically in clock synchronous
system and asynchronous system. SCLK is exclusively for use with clock synchronous system and func-
tions as a synchronous clock input/output terminal. SRDY is exclusively for use in clock synchronous
slave mode and functions as a send-receive ready signal output terminal.
When asynchronous system is selected, since SCLK and SRDY are superfluous, the I/O port terminals P12
and P13 can be used as I/O ports.
In the same way, when clock synchronous master mode is selected, since SRDY is superfluous, the I/O port
terminal P13 can be used as I/O port.

4.11.2 Mask option

Since the input/output terminals of the serial interface is shared with the I/O ports (P10–P13), the mask
option that selects the output specification for the I/O port is also applied to the serial interface.
The output specification of the terminals SOUT, SCLK (for clock synchronous master mode) and SRDY
(for clock synchronous slave mode) that are used as output in the input/output port of the serial interface
is respectively selected by the mask options of P11, P12 and P13. Either complementary output or N-
channel open drain output can be selected as the output specification. However, when N-channel open
drain output is selected, do not apply a voltage exceeding the power supply voltage to the terminal.

Furthermore, the pull-up resistor for the SIN terminal and the SCLK terminal (for clock synchronous
slave mode) that are used as input terminals can be selected by the mask options of P10 and P12.
When "without pull-up" is selected, take care that the floating status does not occur.

4.11.3 Transfer modes

There are four transfer modes for the serial interface and mode selection is made by setting the two bits of
the mode selection registers SMD0 and SMD1 as shown in the table below.

Table 4.11.3.1 Transfer modes

SMD1/SMD1S SMD0/SMD0S

Mode

1

1

0

0

1

0

1

0

8-bit asynchronous

7-bit asynchronous

Clock synchronous slave

Clock synchronous master

Table 4.11.3.2 Terminal settings corresponding to each transfer mode

Mode

SIN

Asynchronous 8-bit

Asynchronous 7-bit

Clock synchronous slave

Clock synchronous master

P13

P13

Output

P13

SOUT SCLK

SRDY

P12

P12

Input

Output

Output

Output

Output

Output

Input

Input

Input

Input

At initial reset, transfer mode is set to clock synchronous master mode.
