S1C63558 TECHNICAL MANUAL EPSON 167
CHAPTER 7: ELECTRICAL CHARACTERISTICS
7.10 Characteristic Curves (reference value)
High level output current (Pxx, Rxx, BZ)
Ta = 70˚C, Max. value
0.0
0
-1
-2
-3
-4
-5
-6
-7
-8
0.2 0.4 0.6
V DD –V OH [V]
V DD = 3.0 V
V DD = 5.0 V
I OH
[mA]
0.8 1.0
Low level output current (Pxx, Rxx, BZ)
Ta = 70˚C, Min. value
1.0
0
2
4
6
8
10
12
14
0.8 0.6 0.4
V OL [V]
V DD = 3.0 V
V DD = 5.0 V
I OL
[mA]
0.2 0.0
