7.6 Serial Interface (1), (2) AC Characteristics
1. Clock synchronous master mode (during 1 MHz operation)
Item
Transmitting data output delay time
Receiving data input set-up time
Receiving data input hold time
Symbol
t smd
t sms
t smh
Unit
ns
ns
ns
Max.
200
Typ. Min.
400
200
Note that the maximum clock frequency is limited to 1 MHz.
Condition: V DD =3.0V, V SS =0V, Ta=-20 to 70
°
C, V IH1 =0.8V DD , V IL1 =0.2V DD , V OH =0.8V DD , V OL =0.2V DD
2. Clock synchronous slave mode (during 1 MHz operation)
Item
Transmitting data output delay time
Receiving data input set-up time
Receiving data input hold time
Symbol
t ssd
t sss
t ssh
Unit
ns
ns
ns
Max.
500
Typ. Min.
400
200
Note that the maximum clock frequency is limited to 1 MHz.
Condition: V DD =3.0V, V SS =0V, Ta=-20 to 70
°
C, V IH1 =0.8V DD , V IL1 =0.2V DD , V OH =0.8V DD , V OL =0.2V DD
SCLK OUT
SOUT
SIN
V OH
V OH
V OL
t sms t smh
t smd
V IH1
V IL1
V OL
SCLK IN
SOUT
SIN
V IH1
V OH
V OL
t sss t ssh
t ssd
V IH1
V IL1
V IL1
3. Asynchronous system
Item
Start bit detection error time
∗
1
Erroneous start bit detection range time
∗
2
∗
1
∗
2
Symbol
t sa 1
t sa 2
Unit
s
s
Max.
t /16
10 t /16
Typ. Min.
0
9 t /16
Start bit detection error time is a logical delay time from inputting the start bit until internal sampling begins operating.
(Time as far as AC is excluded.)
Erroneous start bit detection range time is a logical range to detect whether a LOW level (start bit) has been input again
after a start bit has been detected and the internal sampling clock has started. When a HIGH level is detected, the start bit
detection circuit is reset and goes into a wait status until the next start bit. (Time as far as AC is excluded.)
Condition: V DD =2.2 to 5.5V, V SS =0V, Ta=-20 to 70
°
C
t sa 1
t
t sa 2
SIN
Start bit
Sampling
clock
Erroneous
start bit
detection signal
Stop bit
