S1C63558 TECHNICAL MANUAL EPSON 1
CHAPTER 1: OUTLINE
CHAPTER
1 O
UTLINE
The S1C63558 is a microcomputer which has a high-performance 4-bit CPU S1C63000 as the core
CPU, ROM (8,192 words
×
13 bits), RAM (5,120 words
×
4 bits), serial interface, watchdog timer, program-
mable timer, time base counters (2 systems), SVD circuit, a dot-matrix LCD driver that can drive a
maximum 40 segments
×
17 commons, DTMF/DP generator, FSK demodulator and sound generator
built-in. The S1C63558 features high speed operation and low current consumption in an operating
voltage range (2.2 V to 5.5 V), this makes it suitable for applications working with batteries. It is also
suitable for caller ID and portable data bank systems because it has a large capacity of RAM built-in.
1.1 Features
OSC1 oscillation circuit ...................... 32.768 kHz (Typ.) crystal oscillation circuit
OSC3 oscillation circuit ...................... 3.58 MHz (Typ.) ceramic oscillation circuit
Instruction set ..................................... Basic instruction: 46 types (411 instructions with all)
Addressing mode: 8 types
Instruction execution time ................... During operation at 32.768 kHz: 61 µsec 122 µsec 183 µsec
During operation at 3.58 MHz: 0.56 µsec 1.12 µsec 1.68 µsec
ROM capacity ..................................... Code ROM: 8,192 words
×
13 bits
Data ROM: 2,048 words
×
4 bits (= 8K bits)
RAM capacity ...................................... Data memory: 5,120 words
×
4 bits
Display memory: 816 bits (192 words
×
4 bits + 48
×
1 bit)
Input port ............................................. 8 bits (Pull-up resistors may be supplemented
∗
1)
Output port .......................................... 12 bits (It is possible to switch the 8 bits to special output
∗
2)
I/O port ................................................ 16 bits (It is possible to switch the 2 bits to special output and
the 4 bits to serial I/F input/output
∗
2)
Serial interface .................................... 2 ch. (8-bit clock synchronous or asynchronous system is selectable)
LCD driver ........................................... 40 segments
×
8, 16 or 17 commons (
∗
2)/48 segments
×
8 commons (
∗
1)
Time base counter .............................. 2 systems (Clock timer, stopwatch timer)
Programmable timer ........................... Built-in, 2 inputs
×
8 bits, with event counter function
Watchdog timer ................................... Built-in
DTMF generator ................................. Built-in
DP generator ...................................... Built-in
FSK demodulator ................................ Built-in (Compatible with ITU-T V.23/Bell 202)
Sound generator ................................. With envelope and 1-shot output functions
Supply voltage detection (SVD) circuit .. 12 values, programmable (2.20 V to 3.30 V)
(It is possible to switch 1 value to the external voltage detection
∗
1)
External interrupt ................................ Input port interrupt: 2 systems
Internal interrupt ................................. Clock timer interrupt: 4 systems
Stopwatch timer interrupt: 2 systems
Programmable timer interrupt: 2 systems
Serial interface interrupt:
6 systems
Dialer interrupt: 1 system
FSK interrupt: 2 systems
Power supply voltage ......................... 2.2 V to 5.5 V
Operating temperature range ............. -20°C to 70°C
Current consumption (Typ.) ................ Low-speed operation (OSC1: crystal oscillation):
During HALT (32 kHz)
3.0 V (LCD power OFF) 1.5 µA
3.0 V (LCD power ON) 4 µA
During operation (32 kHz) 3.0 V (LCD power ON) 10 µA
High-speed operation (OSC3: ceramic oscillation):
During operation (3.58 MHz) 3.0 V (LCD power ON)
600 µA
During FSK operation 5.5 V (LCD power ON) 1,800 µA
Package .............................................. QFP15-128pin (plastic) or chip
∗
1: Can be selected with mask option
∗
2: Can be selected with software
