Xpanel User Manual 5-9
Adding events and actions to primitives and objects
4. Select the O N T ALLY (DSK S TATE -F ILTERED ) tally event and add the Set Back Color
action to turn the button’s background color to red when the tally reports keyer 1 is cut up.
a.
Click the A DD ACTION button to add an action.
b. Select S ET B ACK C OLOR from the drop-down list of actions.
c. Specify the Set Back Color’s Action Parameters to:
• T
ARGET : Control:Button1
• C OLOR : 255,0,0
5. Select the O N T ALLY (DSK S TATE -F ILTERED ) tally event and add Set Text action to
change the button’s text to “ON” when the tally reports keyer 1 is cut up.
a.
Click the A DD ACTION button to add an action.
b. Select S ET T EXT from the drop-down list of actions.
c. Specify the Set Text’s Action Parameters to:
• T
ARGET : Control:Button1
• S OURCE : ON
6. Select the O N T ALLY (DSK S TATE -F ILTERED ) tally event and add the Set Property action
to change the button’s state to match the tally’s state.
a.
Click the A DD ACTION button to add an action.
b. Select S ET P ROPERTY from the drop-down list of actions.
c. Specify the Set Property’s Action Parameters to:
• T
ARGET : Control:Button1
• P ROPERTY : State
• V ALUE : Tally:State
