4-30 Xpanel User Manual
Building and editing panels
Health Meter Playout devices can be configured to continually monitor and set off
alarms to identify error conditions that may affect the performance or
health of the device.
Adding H EALTH M ETER objects to a panel allows operators to monitor the
current readings of a device and be alerted if an alarm occurs. If the
reading for the particular device condition falls outside of the expected
range, an alarm is triggered and the Health Meter’s LED turns red to alert
the operator of the potential problem. An alarm can be turned on or off by
toggling the O
N button.
Health Meter objects can only monitor one type alarm at a time. Therefore,
you must choose one of the following alarm types from the object’s
H
EALTH V ALUE property:
Hard Panel Brightness The H ARD P ANEL B RIGHTNESS object adds an Up Down box or slider to the
panel so that operators can adjust the brightness of the RCP-BR device’s
touchscreen, where 1 is the dimmest and 8 the brightest.
The Hard Panel Brightness object’s A PPEARANCE property determines if
the control is an U P D OWN BOX or a S LIDER . The object’s O RIENTATION
property determines whether the slider is horizontal or vertical.
Other objects Description
