Xpanel User Manual
5-1
5 A
DDING
EVENTS
AND
ACTIONS
TO
PRIMITIVES
AND
OBJECTS
Xpanel’s Action Editor allows you to configure the panel, primitives or control objects to
perform actions in response to events or changes in tallies from the devices. A simple
example to illustrate this concept is that a button primitive (the object) on a control panel
can be set in the Action Editor so that when it is clicked (the event) during playout, a specific
audio file starts to play (the action).
To configure the panel, primitives and/or objects to perform actions based on events
or changes in tallies:
1.
In Xpanel’s Design mode, open the Action Editor (C
TRL
+E).
2.
Select the primitive, object or panel.
3.
Select a standard event from the Action Editor (applies only to: panels, primitives,
channel selectors, text objects, image objects and bevel objects).
Or,
Add a user event or tally event to the Action Editor.
4.
With the event selected, do one of the following:
• Add an I
F
condition and define the condition using the Expression Builder.
Add actions to the condition and set the actions’ parameters.
Or,
• Add an I
F
condition and define the condition using the Expression Builder.
Add action(s) to the event’s conditions and set the action’s parameters.
Add an E
LSE
statement and add actions to the Else statement and set the
action’s parameters.
Or,
• Add actions directly to the event and set the actions’ parameters.
The following sections provide functional descriptions and instructions for using the Action
Editor to add actions and events to primitive objects:
•
“Selecting a standard event” on page 5-2
•
“Adding a user event” on page 5-4
•
“Adding a tally event” on page 5-7
•
“Adding actions to an event” on page 5-12
•
