8-6
Xpanel User Manual
A Quick reference to Xpanel’s menus & toolbars
Properties
Design mode only.
Opens the P
ROPERTIES
view, which displays the current properties
and settings belonging to the selected object(s) or the panel’s
canvas. See
“Configuring the panel’s properties” on page 4-4
and
“Configuring an object’s properties” on page 4-7
for more
information.
Alternative access:
•
Keyboard shortcut: C
TRL
+R
Object List
Design mode only.
Opens the O
BJECTS
view, which displays a list of the objects that
are currently on the panel. Selecting an object in the Objects view
selects the object on the panel.
Right-clicking the object allows you to select the Set as a drag &
drop default and Reset the drag & drop default commands.
Asset Browser
Design mode only.
Opens the A
SSET
B
ROWSER
view, which allows you to browse and
preview the Panels, Images, Data schemas that are stored on the
system. Panels can be opened directly from the Asset Browser,
images can be dragged onto the canvas and new data schemas
can be created and linked to objects.
Alternative access:
•
Keyboard shortcut: C
TRL
+A
Action Editor
Design mode only.
Opens the A
CTION
E
DITOR
view, which allows you to add to the
functionality of standard Xpanel objects or define the functionality
of primitive objects by configuring and associating the objects with
a set of actions to occur on an event. See
actions to primitives and objects” on page 5-1
for more information.
Alternative access:
•
Keyboard shortcut: C
TRL
+E
Script Editor
Design mode only.
Opens the S
CRIPT
E
DITOR
view, which allows you to create or edit
custom VB scripts to provide more complex functionality to actions
associated with Xpanel objects.
Station Manager
Design mode only.
Opens the S
TATION
M
ANAGER
view, which allows you to define the
devices on the network and then create a station configuration,
which groups the devices into channels. See
