Xpanel User Manual 4-19
Building and editing panels
Image Position The I MAGE P OSITION object produces a slider or an Up Down box that
allows operators to set or reposition the horizontal and/or vertical center of
the media content loaded on the keyer.
•
S LIDER A PPEARANCE : Determines if the control is a slider (T RUE ) or an
Up Down box (F ALSE ).
• O RIENTATION : If the Slider appearance property is set to T RUE , this
property determines whether the slider is horizontal or vertical.
• P OSITIONING T YPE : Determines if the Image Position object will control
the image’s X position or Y position.
• P OSITIONING M ODE : Determines the precision by which the Image
Position object will control the movement of the image. Choose from
either C
OARSE or F INE .
The following example demonstrates a K EYER V IEWER object and two
I MAGE P OSITION objects that allow us to view and control the positioning of
the image that is loaded on the keyer.
Note: In Production mode, clicking a precise point in the Keyer Viewer
moves the image to that position and the Image Position object’s values
are immediately updated.
DSK objects Description
