3-8 Xpanel User Manual
Creating and loading a station configuration
Loading a station configuration
When creating or editing panels in Xpanel’s Design mode, a station configuration must be
loaded so that you can set panel objects to control specific channels or devices.
Also note that a station configuration must be loaded in Xpanel in order to access Xpanel’s
Production mode. Whether switching from Design mode to Production mode or if Xpanel’s
Startup options are configured to open in Production mode, Xpanel will not open Production
mode until a station configuration is loaded first. Select Yes to open Xpanel’s Options window
and following the instructions below for loading a station configuration.
The two methods for loading a station configuration are described below.
Loading a station configuration using Xpanel’s Options:
1.
Select the T OOLS >O PTIONS menu command.
The Options window appears.
2. Select the S ETUP tab and click the L OAD button in the Station configuration section.
The O PEN S TATION C ONFIGURATION window appears.
3. Select the station configuration that you want to load and click O PEN .
The station configuration’s name now appears in the S TATION NAME field in the O PTIONS
window.
4. Click OK.
