Xpanel User Manual 4-49
Building and editing panels
Exporting and importing a panel or project
To transfer panels and projects between two separate Vertigo Suite installations, you can
export the panels or project from one and import them into the other. Exporting wraps the
panel’s or project’s components into a portable VxM Export file folder, which can then be
transferred to and imported into a separate Vertigo Suite installation.
N
OTE
Since station configuration is not exported with the panels/project, once the panels are
imported into the new system, you must re-assign the channels and devices to each object
on the panel and/or channel selector.
To export a panel or project:
1.
With the panel or project open in Xpanel, select F ILE >E XPORT and then select either the
E XPORT PANEL or E XPORT PROJECT command.
If the panel or project contains unsaved changes, you will be prompted to save before
proceeding.
The S
AVE A S window appears and automatically assigns the VxM_Export_* file
name and type.
N
OTE
You can only export a single panel at a time when using the E XPORT PANEL command. To
export multiple panels in batches, consider grouping the panels into a project ( page 4-48 )
and then exporting the project.
2. Select the destination directory for the export file and click S AVE .
The Export folder can now be transferred to the new system.
To import a panel or project:
1.
After transferring the VxM Export folder to the new system and launch Xpanel.
2. Select F ILE >I MPORT and then select either the I MPORT PANEL or I MPORT PROJECT
command.
The I
MPORT PANEL WITH ASSETS window appears.
3. Navigate to the directory where the VxM Export folder is located.
4. Open the Vxm Export folder and double-click the VxM_Export_*.exp file.
5. The Import window appears and identifies all of the assets that will be imported from
the export file to the target XMS. An icon in front of the asset’s name indicates whether
the asset is being added
or is being updated .
