Xnews User Manual 4-9
Preparing to use Xnews
5. Select the T EMPLATE tab to return to the Template side.
6. Link the template side’s image texture to the scene’s clip object by dragging the clip
object in the scene tree and dropping it onto the image texture (figure
4-12 ).
Be sure to place and size the clip object within the scene’s safe areas.
Figure 4-12. Link the scene’s clip object to the template’s image texture
7. Save the template to the Xmedia Server by selecting F ILE >S AVE . Specify a name and
category for the template in the S AVE T EMPLATE window. Then, click OK.
Specifying the clip template on a device’s configuration
To specify a clip template on a device’s configuration:
1.
Open the clip template in Xstudio and take note of its name, category location, and the
name of the texture on the template side.
2. Open the D EVICE M ANAGER window by selecting T OOLS >D EVICES >C ONFIGURE D EVICES .
The Device Manager (D EVICE C ONFIGURATION window) appears (figure 4-13 ).
Figure 4-13. The Device Manager
3. If the device is connected (appears in the Device box on the right side), click the left
arrow button
to disconnect it and make it available for editing.
The device box becomes empty.
