80 INDIGO AV Mixer User Manual
Section 7 — Menus
SD Key 1/2 In/Out
For the fade-in and fade-out of the SD keyers, the following effect catego-
ries are available:
• Wipe
• Mix
• 3D
• Slide
• Squeeze
Overview of SD Effect Patterns
The following table shows all available SD transitions. Some of them are
only available for
SD BGND .
Effect Pattern Categories
Wipe Mix 3D Page Roll Page Turn Slide Squeeze Door
Left Mix Ripple Left Left Left Left Left
Top White Mix Sphere Right Right Right Right Right
T Left Black Mix Swirl Top Top Top Top Top
T Right Matte Mix Rock Bottom Bottom Bottom Bottom Bottom
B Right Blind 4 T Left T Left T Left T Left Hor
B Left Discont T Right T Right T Right T Right Vert
Cross B Right B Right B Right B Right
Rect x4 B Left B Left B Left B Left
Square45 2 Hor 2 Hor Hor
Slit V 2 Vert 2 Vert Vert
Slit H 4 Multi 4 Multi Center
Diag A 8 Multi 8 Multi
Diag B 16 Multi 16 Multi
Vertex R 32 Multi 32 Multi
Vertex L 64 Multi 64 Multi
Rect 128 Multi 128 Multi
Circle Inf Multi
Star 2 Out
Clock Inf Out
Clock4
Angle
Matrix 1
Matrix 2
Rings
Slit4 H
Slit4 V
