156 INDIGO AV Mixer User Manual
Section 10 — Maintenance
10.4.2 Transition Lever Arm (T-Bar)
To calibrate the Transition Lever Arm:
1. Select SETUP main menu.
2. Select CONTROL PANEL submenu.
3. Press Calib. button.
4. Press T-Bar button to enter calibration mode.
5. Move the Transition Lever Arm up as indicated by the calibration
procedure.
6. Press the OK button.
7. Move the Transition Lever Arm down as indicated by the calibration
procedure.
8. Press the OK button.
9. Press OK again to store the calibration.
