Audio Connections
The following table shows the pin assignment grouped by inputs and out-
puts:
Note The optional adapter INDIGO1-AUDIO_CABLE connects two XLR outputs
and six XLR inputs with the 25pin AES/EBU connector of your INDIGO AV
Mixer. The cable length is three meters.
Digital Audio Input Description Pin
1
IN1+ 1
IN1- 14
IN1com 2
2
IN2+ 15
IN2- 3
IN2com 16
3
IN3+ 4
IN3- 17
IN3com 5
4
IN4+ 18
IN4- 6
IN4com 19
5
IN5+ 7
IN5- 20
IN5com 8
6
IN6+ 21
IN6- 9
IN6com 22
Digital Audio Output Description Pin
1
OUT1+ 10
OUT1- 23
OUT1com 11
2
OUT2+ 24
OUT2- 12
OUT2com 25
