7 General Properties
7.1 FPGA Mounted on SMT338-VP
All FPGA interfaces on the SMT338-VP require 508 IOs. The following table is a
summary of the amount of IOs available on Xilinx Virtex-II Pro devices.
Size (mm) XC2VP7 XC2VP20 XC2VP30 XC2VP40 XC2VP50
FF672 27 x 27 396 / 8
FF896 31 x 31 396 / 8 556 / 8 556 / 8
FF1152 35 x 35 564 / 8 644 / 8 692 / 12 692 / 16
Table 6. Virtex-II Pro IO Count.
By default all SMT338-VPs are assembled with VP30 devices. The example firmware
is also for a VP30 FPGA. If a VP7 is mounted some of the SHB interface IOs and the
DDR SDRAM memory interface will be lost.
7.2 Design Resource Usage
The following table is a summary of the FPGA resources used by the demo design
that comes with the SMT381-VP (compiled for a VP30 device).
Resource Utilization Percentage
Number of External DIFFMs 37 out of 276 13%
Number of External DIFFSs 37 out of 276 13%
Number of External IOBs 266 out of 556 47%
Number of LOCed External IOBs 249 out of 266 93%
Number of RAMB16s 72 out of 136 52%
Number of SLICEs 6640 out of 13696 48%
Number of BUFGMUXs 13 out of 16 81%
Number of DCMs 7 out of 8 87%
Table 7. Virtex-II Pro Device Utilization Summary.
7.3 Power Supply
The following voltages are required by the SMT381 and must be supplied over the
daughter card power connector.
