TopKAT PLUS Installation Procedures Post-installation Checklist
Page 3-26 MDE-5013C TopKAT™ PLUS Installation Manual · February 2015
Post-installation Checklist
After completing the installation procedure, inspect carefully the connection between the
TopKAT PLUS, external power mains, and data sources.
In particular, pay attention to the following issues:
Completion Checklist
Following information will help in verifying if the TopKAT PLUS is properly installed.
Review it before testing the pumps and/or dispensers in the manual override position.
Check if all the conduit is metal conduit (refer to the “Reference Information” section in
MDE-4331 Atlas Fuel Systems Installation Manual).
Correct wiring
• Check if all the wiring is inserted in metal conduits.
• Check if the system is grounded properly.
• Check if the cables are correctly routed in the dispenser.
Clean dirt and wire remnant
Verify if power supply setup jumpers (see Figure 3-11 on page 3-13 ) are properly set BEFORE applying
power to the TopKAT PLUS. In case problems are detected after installation or during operation, repeat
the post-installation checks listed above.
Check if AC and DC wirings are in separate conduits and troughs.
Check if the systems/peripheral equipment is there on a separate dedicated breaker.
Check if the system is grounded properly (refer to the “Reference Information” section in MDE-4331 Atlas
Fuel Systems Installation Manual).
Check if the correct wire gauge wire is installed (refer to the “Reference Information” section in MDE-4331
Atlas Fuel Systems Installation Manual).
Check if the communication lines are under the maximum allowable distance - LAN:280’, RS-485 = 1500’
MAX, and RS-232 = 100’.
Check if the AC power for the systems and pumps is on the same phase in the breaker panel.
