Gasboy TopKAT PLUS User Manual
Page 34
TopKAT PLUS Installation Procedures
TopKAT PLUS Pedestal Mounting Instructions
Page 3-8
MDE-5013C TopKAT™ PLUS Installation Manual · February 2015
b
Ensure that you do not remove the cover completely until the yellow ground wire that
connects the cover to the grounding lug of the unit is removed.
Note: The front of the pedestal has the overhang, and the mounting studs are arranged in such
a manner that the TopKAT head assembly can only be mounted one way, facing
frontwards (see
).
Figure 3-6: TopKAT PLUS Pedestal
Rear View
Side View
Top Mounting Studs
Facing Front
