TopKAT PLUS Installation Procedures Mechanical Pump - Wiring
Page 3-14 MDE-5013C TopKAT™ PLUS Installation Manual · February 2015
Mechanical Pump - Wiring
Dangerous AC voltages that can cause death or serious personal injury are used to power
the product. Always disconnect power before starting any work.
WARNING
General
This device is intended to be connected to UL-listed dispensers equipped with a J-box of
sufficient volume. These connections are not suitable for direct connection to intrinsically safe
devices. All wiring is to be in compliance with NFPA 70 and NFPA 30A.
The wiring for mechanical pumps is provided in two modes:
• Following table lists the wiring in the sequential order of the terminals. This table provides
the signal name and a functional description of the signal.
• Figure 3-12 on page 3-15 shows the wiring list for connection to the terminal, as published
in the wiring label attached to the inner side of the unit. The wiring label follows the
physical location of the wires in the terminal block.
Terminal Block - Pin-out Connections for Mechanical Pumps
Following table lists the TopKAT PLUS terminal block connections for mechanical pumps:
Terminal
No.
Signal Name Functional Description
1 LINE_IN_(115/230 V) Line Connection, TopKAT PLUS Power Input
2 NEUTRAL_IN_(115/230 V) Neutral Connection, TopKAT PLUS Power Input
3 GROUND_IN_(115/230 V) Ground Connection, TopKAT PLUS Power Input
4 LINE_1 Pump Control 220/110 VAC Input - Nozzle 1
5 LOAD_1 Pump Control Output - Nozzle 1
6 LINE_2 Pump Control 220/110 VAC Input - Nozzle 2
7 LOAD_2 Pump Control Output - Nozzle 2
8 IN_USE_1_ A(AC) Handle Up - In Use Signal Input - Nozzle 1
9 IN_USE_1_ B(RETURN) Handle Up - AC In Use Signal Return - Nozzle 1
10 IN_USE_2_ A(AC) Handle Up - In Use Signal Input - Nozzle 2
11 IN_USE_2_ B(RETURN) Handle Up - AC In Use Signal Return - Nozzle 2
12 -DC OUT FOR BY-PASS_2 Connection to External Bypass Nozzle 2
13 BY-PASS_2_IN Connection to External Bypass Nozzle 2
14 PULSER_1 Pulser Input - Nozzle 1
15 PULSER_2 Pulser Input - Nozzle 2
16 +12 V_2_P +12 VDC Output to Pulser - Nozzle 2
17 -DC OUT FOR BY-PASS_1 Connection to External Bypass Nozzle 1
18 BY-PASS_1_IN Connection to External Bypass Nozzle 1
19 GND_1_P Nozzle Grounding - Nozzle 1
20 GND_2_P Nozzle Grounding - Nozzle 2
21 +12 V_1_P +12 VDC Output to Pulser - Nozzle 1
