Topkat plus main components location – Gasboy TopKAT PLUS User Manual
Page 15
MDE-5013C TopKAT™ PLUS Installation Manual · February 2015
Page 1-9
TopKAT PLUS Structure
Introduction
TopKAT PLUS Main Components Location
shows the location of the main components of the TopKAT PLUS.
Figure 1-9: Internal Components Location
OrPT
OrCU
Printer
8-port
CommVerter
AC
Protective Cover
Terminal Block
Connection
Openings
Cover Opening
Detection
Mechanism
Ground Stud
