MDE-5013C TopKAT™ PLUS Installation Manual · February 2015 Page 3-7
TopKAT PLUS Pedestal Mounting Instructions TopKAT PLUS Installation Procedures
TopKAT PLUS Pedestal Mounting Instructions
The TopKAT PLUS head assembly and pedestal assembly are packaged in their own boxes
and shipped in a large box. After removing them from the large box, the two units must be
connected together using the following procedure.
Parts List
Following parts are required for the TopKAT PLUS pedestal mounting:
• Pedestal and Head Assembly
Description
TopKAT PLUS
Pedestal
Assembly TopKAT PLUS
Head Part
Number Orpak

OrTOP 
Part Number
TopKAT PLUS Pedestal - Electronic Dispenser OrTOP (E) PA040500000 PA040500100 800938970
TopKAT PLUS Pedestal - Mechanical Dispenser OrTOP (2M) PA040501000 PA040501100 800938972
TopKAT PLUS Pedestal - Electronic Dispenser
with Printer
OrTOP (E, PRN) PA040500010 PA040500110 800938971
TopKAT PLUS Pedestal - Mechanical Dispenser
with Printer
OrTOP (2M, PRN) PA040501010 PA040501110 800938973
TopKAT Pedestal M12706002 - -
• Hardware Kit
• Gasket
• Installation Instructions
To install the TopKAT PLUS pedestal, proceed as follows:
1 Install and secure the pedestal to the island using the four holes at the bottom of the pedestal
with anchor bolts before installing the head assembly. This will prevent the completed
assembly from possibly falling over.
Note: To access the four inside bottom mounting holes, remove the rear lower door panel.
2 Position the pedestal so that the front side faces the fueling lane. Secure the pedestal to the
island using the four mounting holes inside the base of the unit.
3 Install the black rubber gasket on top of the pedestal ensuring that the holes for the wiring are
aligned properly and not blocked.
4 Mount the TopKAT head assembly onto the top of the pedestal using the four threaded studs as
a guide. Secure the head assembly using a flat washer, lockwasher, and 1/4-20-inch nut onto
each of the four post and tighten.
a Remove the TopKAT cover by unlocking the rear key lock and slide the cover to the rear
side of the unit.
