MDE-5013C TopKAT™ PLUS Installation Manual · February 2015 Page 3-19
Mechanical Pump - Pulser Connections TopKAT PLUS Installation Procedures
Mechanical Pump - Pulser Connections
This paragraph describes the required wiring connections between the pulser in the
mechanical pump and TopKAT PLUS. The system can accept many types of pulsers. For more
information, contact Gasboy. Two types of pulsers can be found in the pumps:
• Electronic pulser
• Mechanical pulser
Connect the TopKAT PLUS to the pulser in accordance with its characteristics.
Following are the TopKAT PLUS ratings for above signals:
Signal TopKAT PLUS Rating
Pulser Input 3 mA, 15 VDC max.
Pulser Power Output 12 VDC, 30 mA max.
In Use Input 100-200 VAC, 50/60 Hz, 2 W (20 mA)
Load 3/4 HP @115 V
1.5 HP @ 240 V
