KPA Ku-Band Indoor Solid-State Power Amplifier Revision 1
Front Panel Operation MN/KPA.IOM
5–17
5.3.3.4 UTILITY: Firmware
IMPORTANT
THESE MENUS ARE INTENDED FOR DIAGNOSTIC PURPOSES ONLY. DO NOT
CHANGE AN IMAGE UNLESS OTHERWISE INSTRUCTED BY COMTECH EF
DATA CUSTOMER SUPPORT.
Firmware Info: Boot Bulk
App FPGA
This series of submenus is used to view information about the KPA internal firmware. Select
Boot, Bulk, App, or FPGA using the
◄ ► arrow keys, then press ENTER.
If Boot is selected:
Boot: FW-0000085
X.X.X MM/DD/YY
If Bulk is selected:
Bulk: FW0000392
X.X.X MM/DD/YY
If App is selected:
App: FW00000393
X.X.X MM/DD/YY
If FPGA is selected:
Boot: FW-0000088
X.X.X MM/DD/YY
5.3.3.5 UTILITY: RefOsc
Note: This display is used for debugging purposes only.
Reference Oscillator:
Information Adjust (◄ ► E)
Select Information or Adjust using the ◄ ► arrow keys, then press ENTER.
If Information is selected, the raw voltage of the voltage tuning monitor and the external
reference status are displayed. For example:
Ref Osc: Vtune = 04.8
ExtRef: N/A
Press ENT or CLR to return to the previous menu.
If Adjust is selected:
Reference Frequency
Adjust 87
The reference oscillator adjustment may be manipulated with this menu. Use the ◄ ► arrow
keys to select the numeral to edit, then the ▲ ▼ arrow keys to edit the value of the selected
