KPA Ku-Band Indoor Solid-State Power Amplifier Revision 1
Front Panel Operation MN/KPA.IOM
5–14
5.3.2.1 MONITOR: Faults
Current Faults: Voltages
PS Temp Fan Other(◄ ► E)
Select Voltages, PS, Temp, Fan, or Other using the
◄ ► arrow keys, then press ENTER.
If Voltages is selected:
+15V = OK +7.5V = OK
+5V = OK -5V = OK (E)
If PS (Power Supply) is selected:
28VDC PS = OK
RF Power Supply = OK
Temp (Temperature) is selected:
TEMP = OK
(E)
If Fan is selected:
FAN1 = OK
FAN2 = OK (E)
If Other is selected:
BUC = OK
ExtRef = OK (E)
5.3.2.2 MONITOR: Stored
Stored Events: View
Clear-All (◄ ► E)
Select View or Clear-All using the ◄ ► arrow keys, then press ENTER.
If View is selected:
Log05: 10/11/10 10:37:32
Info - Log CLEAR (▲ ▼)
The user may scroll backwards or forwards through the entries in the stored events log by
using the
▲ ▼ arrow keys. Press ENTER or CLEAR to return to the previous menu. The
stored events log can store up to 255 events.
The top line of the display indicates the log entry number, and the date and time of the entry.
IMPORTANT
Note that in accordance with European convention, the date is shown in
DAY-MONTH-YEAR format.
The bottom line of the display shows the event that has been logged and stored.
