Comtech EF Data KPA - Manual (Page 53)

KPA Ku-Band Indoor Solid-State Power Amplifier Revision 1
Front Panel Operation MN/KPA.IOM
5–9
The user may view or edit the SNMP Write Community string. To edit, first use the ◄
►arrows keys to select the character to edit, then the ▲ ▼ arrows keys to edit that
character. Press ENTER when done.
If SNMP Community: Trap is selected:
Trap Community:(◄ ► ▲ ▼ E)
comtech
The user may view or edit the SNMP Trap Community string. To edit, first use the ◄
►arrows keys to select the character to edit, then the ▲ ▼ arrows keys to edit that
character. Press ENTER when done.
Note: For the preceding menus, only the first 20 characters on the bottom line are
available. All printable ASCII characters are available with the exception of the
backslash (ASCII code 92) and ~ (ASCII code 126). When the user has composed the
string and has pressed ENTER, all trailing spaces are removed from the Community
string upon entry.
If SNMP: Traps is selected:
SNMP Trap IP Address:
IP1 IP2 Version
Use the ◄ ► arrow keys to select IP1, IP2, or Version, then press ENTER.
If SNMP Trap IP Address: IP1 or IP2 is selected:
Trap IP #1:
000.000.000.000(◄ ► ▲ ▼ E)
Trap IP #2:
000.000.000.000(◄ ► ▲ ▼ E)
The user may edit the Trap Destination’s IP Addresses. To edit, first use the ◄ ►
arrow keys to select the digit to edit, then the ▲ ▼ arrow keys to edit the value of that
digit. Press ENTER when done.
Note: If both Trap IP Addresses are 000.000.000.000, it means Traps are disabled.
If SNMP Trap IP Address: Version is selected:
Trap Version:
SNMPv1 SNMPv2 (◄ ► E)
Select the trap version – SNMPv1 or SNMPv2 – using the ▲ ▼ arrow keys, then
press ENTER.
