Comtech EF Data KPA - Manual (Page 120)

KPA Ku-Band Indoor Solid-State Power Amplifier Revision 1
Appendix C MN/KPA.IOM
C–24
Utility Status Utility Status:
Confirmation:
>DEV/RUS_'cr'
COMM_aaaaaa'cr'
ADD_xxx'cr'
BR_nnnn'cr'
PAR_nn'cr'
CON_xx'cr'
LCD_xx'cr''lf'] Where:
RS-232 or RS-485
Address (001 to 255)
Baud Rate (300 to 9600)
Parity (OD or EV)
LCD Contrast (0 to 30)
LCD Brightness (0 to 30)
Alarm Status
KPA-020IN Alarm Status:
Confirmation:
>DEV/RAS_'cr'
+28_xx'cr'
+12_xx'cr'
–12_xx'cr'
+5_xx'cr'
–5_xx'cr'
+9_xx'cr'
TEMP_xx'cr'
FAN1_xx'cr'
FAN2_xx'cr''lf'] Where:
+28 VDC Fault
+12 VDC Fault
-12 VDC Fault
+ 5 VDC Fault
– 5 VDC Fault
+ 9_xx'cr'
TEMP_xx'cr'
FAN1_xx'cr'
FAN2_xx'cr'' lf']
Alarm Status
KPA-040 Alarm Status:
Confirmation:
>DEV/RAS_'cr'
+28_xx'cr'
+12_xx'cr'
–12_xx'cr'
+5_xx'cr'
–5_xx'cr'
+9_xx'cr'
TEMP_xx'cr'
SHTD_xx'cr'
FAN1_xx'cr'
FAN2_xx'cr'
PROC_xx'cr''lf'] Where: xx = OK or FT
+28 VDC Fault
+12 VDC Fault
-12 VDC Fault
+ 5 VDC Fault
– 5 VDC Fault
+9 VDC Fault
TEMP_xx'cr'
Over Temperature Shutdown
FAN1 Fault
FAN2 Fault
Processor Fault
Note: A temperature fault is indicated if the unit is
≤ -12°C or ≥
+80
°C. This creates a summary fault and will cause the unit to
mute itself and switchover to the back-up unit. However, the
9V supply to the FET transistors will remain on until the unit
reaches the thermal shutdown temperature of
≥ 89°C. For
protection reasons, the unit will shutdown the 9V supply to
the power transistors at temperatures
≥ +89°C.
